LD Systems ICOA 15A BT – 15″ Inch High Powered Coaxial PA Loudspeaker with Bluetooth
• A genuine all-rounder for Full-Range, Satellite and Monitor applications
• 128 dB SPL and 1200 watts peak power
• Adjustable Vertical and Horizontal use thanks to coaxial design with rotating CD Horn
• BEM-optimised CD horn (Patent pending)
• Horn-loaded woofer
• DynX DSP with 4 presets, 3-band EQ and delay function
• 2 x line/mic input channels with individual gain controllers
• Mono mix output and Bluetooth® streaming
• 36mm dual tilt stand attachment with 0° and 5° tilt angle, 55° monitor angle with sturdy stand
• 6 x integrated M10 flying points
• Shock-resistant front grille for optimal protection of the speaker
• 4 aluminium grips with ergonomic, rubber surface
• Extensive, optionally available accessories for installation and transport
This full-range loudspeaker impresses with its outstanding sound, even at low frequencies. The ICOA 15 A BT by LD Systems is a genuine all-rounder that offers unparalleled features for its class. Its coaxial design, rotating, BEM-optimised CD horn and extensive and precisely calibrated DynX DSP presets make this active 15″ loudspeaker exceptionally flexible.
The outstanding bass reproduction from the horn-loaded woofer makes the LD ICOA 15 A BT the ideal choice for musicians, bands, entertainers and dance schools. It also allows DJs to play sets without the need for a subwoofer. Deployed vertically, the speaker impresses as a satellite; horizontally, it’s excellent in suspended systems or as a floor monitor. The efficient class-D power amplifier delivers 128 dB max. SPL and 1200 W peak performance.
Drawing on DynX DSP technology by LD Systems, the speaker delivers perfect performance with maximum clarity and power under all conditions. 4 presets, a 3-band EQ and a delay function facilitate optimal adjustment of the sound to the venue conditions. The 2 line/mic input channels with individual gain controllers, plus mono mix output, allow a variety of signal sources to be connected. The BT version offers Bluetooth® streaming and the wireless connection of playback devices – ideal for playing content from a phone or tablet.
Thanks to its shock-resistant front grille and ideal 55° tilt angle, the LD ICOA 15 A BT is also outstanding as a floor monitor. Placed vertically, the 36 mm dual tilt stand attachment offers the choice of a 0° or 5° tilt angle for optimally adapting the system to the local acoustic environment.
Extensive and smart accessories for installation and transport are optionally available. 4 aluminium handles with an ergonomic rubber surface provide optimal grip when carrying the speaker.
• Product type: High Performance Powered PA loudspeaker
• Bluetooth: Yes – Onboard Bluetooth 4.0 Audio Decoder
• Low Frequency Driver: 15″ (382mm) Woofer
• Woofer Magnet: Ferrite
• High Frequency Driver: BEM optimized CD Horn
• HF Driver Dimensions: 1″ (25.4 mm)
• HF Driver Magnet: Ferrite
• HF driver voice coil size: 1.4″ (35mm)
• HF Horn Dispersion (H x V): 90° x 50°
• Amplifier: Class D
• System Power: 300w RMS / 1200w Peak
• Frequency response: 48 Hz – 20000 Hz
• Crossover frequency kHz: 2 kHz
• Max. SPL: 128 dB
• Protection circuits: Multiband limiter, over voltage, over-current, thermal overload
• Controls: 2 x gain, On/Off switch, Rotary/push encoder
• Indicators: LCD display
• Mic/Line inputs: 2
• Mic/Line Input Connectors
• 6.35mm jack/ XLR Combination sockets (symmetrical)
• Line inputs: 1 x 3.5mm TRS
• Line outputs: 1 x XLR
• Operating voltage: 240VAC/50Hz
• Fuse: T4AL 250 V
• Cabinet Material: High Impact Polypropylene
• Cabinet Design: Bass Reflex
• Mounting: 36mm Dual Angle Flange (0°, 5°), 6 x M10 flying points
• Monitor Angle: 55°
• Dimensions: W41.6 x H69.5 x D41.5cm
• Weight: 24.3 kg
• Accessories (included): 240VAC-IEC Cable
